Model | ZL38-39B | ||||||||
Working Voltage Range | DC:6V-24V | ||||||||
Rating Power | 6V: 0-16W / 12V: 0-16W / 24V: 0-24W | ||||||||
Static Water Head | 0-6M | ||||||||
Static Flow Rate | 0-14L/min | ||||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000Hr | ||||||||
Working Environment | Liquid: From weak acid to weak base, workable on land (Non-Submerged) | ||||||||
Max Noise | Under normal working status, 1M distance over test instrument <40dB | ||||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature≤100℃( Aluminum alloy shell) | ||||||||
Application | ipeline hot water circulation, solar water heater, small fountain, aquarium, etc. | ||||||||
Size | IP Grade | Inlet | Outlet | remark | |||||
Length（mm） | Width（mm） | Height（mm） | OD（inch） | ID（mm） | OD（inch） | ID（mm） | Inlet and Outlet with Standard screw thread | ||
47 | 65 | 90 | IP67 | G1/2〞Standard thread pipe | φ13 | G1/2〞Standard thread pipe | φ13 | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
