Model | ZL50-33 | ||||||||
Working Voltage Range | DC: 6-24V | ||||||||
Rating Power | 6V: 0-18W 12V: 0-18W 24V: 0-22W | ||||||||
Static Water Head | 0-6.5 M | ||||||||
Static Flow Rate | 0-28L/min | ||||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000hrs | ||||||||
Working Environment | Liquid: From weak acid to weak base, workable both on land and in water (Submersible) | ||||||||
Max Noise | Under normal working status, 1M distance over test instrument <45dB | ||||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature≤70℃ | ||||||||
Application | Car shower, Pipe pressurization, solar water heater, small fountain/aquarium, etc. | ||||||||
Size | IP Grade | Inlet | Outlet | Remarks | |||||
Length（mm） | Width（mm） | Height（mm） | OD（mm） | ID（mm） | OD（mm） | ID（mm） | Inlet and outlet have twistlock | ||
77.0 | 68.0 | 109 | IP68 | φ20 | φ16 | φ20 | Φ16 | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
