Working Voltage Range

DC:  6V-24V

Rating Power

6V: 0-59W / 12V: 0-59W / 24V: 0-86W

Static Water Head

0-15 M

Static Flow Rate

0-19 L/min

Lifespan

Continuous operation≤24hrs, under normal working surrounding >20000hrs

Working Environment

Liquid: From weak acid to weak base, workable on land (Non submergible)

Max Noise

Under normal working status, 1M distance over test instrument <50dB

Max Working Temperature

Under normal surroundings, fluid medium temperature ≤90℃

Application

High building water supply, Garden sprinklers, irrigation, etc.

Size

IP Grade

Inlet

Outlet

Remarks

Length（mm）

Width

（mm）

Height（mm）

OD

（inch）

ID

（mm）

OD

（inch）

Ellipsoid（mm）

Inlet and outlet with standard thread

118

112

110

IP67

G1/2″ standard pipe thread

φ11

G1/2″ standard pipe thread

Major diameter12minor diameter9.6
